In modern wireless communication systems, duplexers, triplexers and quadplexers are key passive components for achieving multi-band signal transmission. They combine or separate signals from multiple frequency bands, allowing devices to transmit and receive multiple frequency bands simultaneously while sharing antennas. Despite the differences in names and structures, their basic principles are similar, with the main difference being the number and complexity of the frequency bands processed.
Duplexer
A duplexer consists of two filters that share a common port (usually an antenna) and are used to implement the functions of transmit (Tx) and receive (Rx) on the same device. It is mainly used in frequency division duplex (FDD) systems to prevent mutual interference by separating transmit and receive signals. Duplexers require a high level of isolation, usually above 55 dB, to ensure that the transmitted signal does not affect the sensitivity of the receiver.
Triplexer
A tripplexer consists of three filters that share a common port. It allows a device to process signals from three different frequency bands simultaneously and is often used in communication systems that need to support multiple frequency bands simultaneously. The design of the triplexer needs to ensure that the passband of each filter does not load other filters and provide sufficient isolation to prevent mutual interference between frequency bands.
Quadplexer
A quadplexer consists of four filters that share a common port. It allows the device to process signals from four different frequency bands simultaneously and is suitable for complex communication systems that require high spectral efficiency, such as carrier aggregation technology. The design complexity of the quadplexer is relatively high and needs to meet strict cross-isolation requirements to ensure that the signals between the frequency bands do not interfere with each other.
Main differences
Number of frequency bands: Duplexers process two frequency bands, triplexers process three frequency bands, and quadplexers process four frequency bands.
Design complexity: As the number of frequency bands increases, the design complexity and isolation requirements also increase accordingly.
Application scenarios: Duplexers are often used in basic FDD systems, while triplexers and quadplexers are used in advanced communication systems that need to support multiple frequency bands simultaneously.
Understanding the working modes and differences of duplexers, triplexers, and quadplexers is critical to designing and optimizing wireless communication systems. Selecting the appropriate multiplexer type can effectively improve the system’s spectrum utilization and communication quality.
